Delivery Options
Worldwide delivery — estimated arrival in 1 business day.
VOE 11103124 – Sealing Ring
Key Features
$38,81
Warranty Information
All VMP products include a standard 6-month warranty.
6 MONTHS
Product Description
Description
The VOE 11103124 Sealing Ring is a Volvo construction equipment spare part. A sealing ring is a precision-formed circular seal that creates a leak-proof barrier between mating surfaces in hydraulic cylinders, valve assemblies and rotating shafts.
This part is categorized under Power Transmission and Front Axle, Rear Axle applications. It is commonly installed on Volvo Articulated Haulers to ensure reliable system performance and operational safety.
VOE 11103124 replaces previous part numbers VOE11102687 and VOE4870575. If your machine was originally equipped with any of these part numbers, this is the updated replacement.
| Model | SN | Old Part |
|---|---|---|
| A25D Volvo | 13001-16369,72001-72433, | VOE11102687 |
| A25D 4×4 Volvo | 72001-72433,13034-16369, | VOE11102687 |
| A30D Volvo | 12001-15909,73001-74658, | VOE11102687 |
| A30D Volvo | 12001-15909,73001-74658, | VOE11102687 |
| A25D Volvo | 13001-16369,72001-72433, | |
| A25D 4×4 Volvo | 72001-72433,13034-16369, | |
| A30D Volvo | 12001-15909,73001-74658, | |
| A30E Volvo | 12001-13131,72001-72639, | |
| A25E Volvo | 73001-73300,13001-13939, | |
| A25E 4×4 Volvo | 73001-,13001-, | |
| A30D Volvo | 60001-60093,10001-11999,70001-72999, | VOE11102687 |
| A25D Volvo | 71001-71999,11001-12999,61001-61118, | VOE11102687 |
| A25D 4×4 Volvo | 11560-12999, | VOE11102687 |
| A30D Volvo | 60001-60093,10001-11999,70001-72999, | VOE11102687 |
| A30D Volvo | 60001-60093,10001-11999,70001-72999, | VOE11102687 |
| A30D Volvo | 12001-15909,73001-74658, | VOE11102687 |
| A30E Volvo | 12001-13131,72001-72639, | |
| A30E Volvo | 12001-13131,72001-72639, | |
| A30D Volvo | 12001-15909,73001-74658, | |
| A30D Volvo | 12001-15909,73001-74658, | |
| A30F Volvo | 52001-,12001-,72701-, | |
| A30F Volvo | 52001-,12001-,72701-, | |
| A30F Volvo | 52001-,12001-,72701-, | |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | VOE11102687 |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | VOE11102687 |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | VOE11102687 |
| A35C Volvo | 4621-11000,60001-70000, | VOE4870575 |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | |
| A35 Volvo | 1001-3408, | VOE4870575 |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | |
| A35D Volvo | 11001-14106,71001-72711,61001-61303, | |
| A35C Volvo | 4001-4620, | VOE4870575 |
| A35C Volvo | 4621-11000,60001-70000, | VOE4870575 |
| A35C Volvo | 4621-11000,60001-70000, | VOE4870575 |
| A35 Volvo | 1001-3408, | VOE4870575 |
| A35C Volvo | 4001-4620, | VOE4870575 |
| A35C Volvo | 4001-4620, | VOE4870575 |
| A30C Volvo | 2321-5000,60001-62000,2276-2908, | VOE4870575 |
| A30C Volvo | 2001-2320,2001-2275, | VOE4870575 |
| A30C Volvo | 2001-2320,2001-2275, | VOE4870575 |
| A30C Volvo | 2001-2320,2001-2275, | VOE4870575 |
| A30 Volvo | 1001-1925, | VOE4870575 |
| A30C Volvo | 2321-5000,60001-62000,2276-2908, | VOE4870575 |
| A30C Volvo | 2321-5000,60001-62000,2276-2908, | VOE4870575 |
| A30 Volvo | 1001-1925, | VOE4870575 |
Steel retaining ring with rubber scraper lip assembled by vulcanization.
Additional information
| Weight | 0,406 kg |
|---|---|
| Brands |
VMP, OEM, ORG |
